8x8 to 320x320 Modular Fiber Optic Matrix Switcher

8x8 to 320x320 Modular Fiber Optic Matrix Switcher

Product Details:

  • Power Source AC/DC
  • Input AC/DC
  • Features High Quality
  • Product Type electrical products
  • Application Electrical & Electronics
  • Size Standard
  • Function Electrical & Electronics Equipment
  • Click to View more
X

8x8 to 320x320 Modular Fiber Optic Matrix Switcher Product Specifications

  • Electrical & Electronics
  • Standard
  • 50 Hertz(Hz)
  • High Quality
  • as shown in the image
  • electrical products
  • Electrical & Electronics Equipment
  • AC/DC
  • AC/DC

Product Description

Key FeaturesLinkLicense for KVM System Configuration and Control packageI/O sizes from 8x8 to 320x320Switches 4K/60 video, audio, USB, control, and 3D sync over fiber optic cableCompatible with all Extron FOX3 Series transmitters and receiversIntegrated IPCP Pro Q xi control processor IPCP Pro ModelsDanteaudio network interface, DMP expansion port, and analog audio inputs and outputs Frame rate3 24, 25, 30, 50, or 60 fps Chroma sampling3 4: 4: 4, 4: 2: 2 Color bit depth2,3 8, 10, or 12 bits per color Signal Type HDMI 2.0, HDCP 2.3 Max. video data rate 18.0 Gbps NOTE 1Supports lossless 4K video over one fiber or uncompressed 4K video over two fibers. 2Supports 12-bit color bit depth for uncompressed 4K video over two fibers. When using a FOX3 SR scaling receiver, the scaler must be in bypass mode to pass 4K video with a 12-bit color bit depth. 3Subject to the maximum data rate limit. Use our calculator atwww.extron.com/8Kdatarateto determine video parameters supported by this data rate. NOTE This product contains Class 1 laser. It meets the safety regulation of IEC 60825-1, FDA21 CFR1040.10, and FDA21 CFR1040.11. Optical specifications Number/type 8singlemode or8 multimode SFPs per board Connectors 16 LC connectors per I/O board Signal Type 8 to 320 fiber optic signals Routing 8x8 up to320 x320 unidirectional matrixor 4x4 up to 160 x160 bidirectional matrix Operating distance Singlemode 20 km (12.4 miles) with singlemode (SM) cables Multimode 500 m (1640 feet) with 50 m OM4 4700 MHz bandwidth laser optimized multimode cables NOTE The system works with OM1, OM2, and OM3 fiber at reduced distances. NOTE Operating distance is approximate. These are typical distances. The maximum distance may be greater than these typical numbers depending on factors such as fiber type, fiber bandwidth, connector splicing, losses, modal or chromatic dispersion, environmental factors, and kinks. Nominal peak wavelength 850 nm for multimode (MM), 1310 nm for singlemode (SM) Transmission power Singlemode -5.2 dBm, typical Multimode -2.8 dBm, typical Receiver sensitivity Singlemode -12.6 dBm, typical Multimode -11.1 dBm, typical Optical loss budget Singlemode +7.4 dB, maximum Multimode +8.3 dB, maximum Maximum channel data rate 10 Gbps Audio input/output board Number/signal type 4analog stereo inputs, balanced/unbalanced 4 analog stereo outputs, balanced/unbalanced Connectors (8) 3.5 mm captive screw connector, 5 pole Source formats 2 channel LPCM Impedance 10 k ohms unbalanced, 20 k ohms balanced Nominal level +4 dBu (1.23 Vrms), -10 dBV (316 mVrms) Maximum level +21 dBu balanced, +15 dBu unbalanced Gain range Adjustable, -18 dB to +24 dB, 1 dB steps Gain Unbalanced output: -6 dB; balanced output 0 dB (default) Frequency response 20 Hz to 20 kHz, 0.5 dB THD + Noise <0.1% @ 20 Hz to 20 kHz at nominal level S/N >90 dB at maximum output (unweighted) CMRR 65 dB @ 20 Hz to 20 kHz Output impedance 50 ohms unbalanced, 100 ohms balanced (analog only) Maximum level (Hi-Z) +21 dBu balanced, +15 dBu unbalanced Gain error 0.5 dB channel to channel Volume control range -100 dB to 0 dB (control 0-100 in 1 dB steps) Crosstalk -80 dB @ 1 kHz, fully loaded Stereo channel separation >80 dB @ 1 kHz Bit Depth 16, 20, 24 Sampling rate 48 kHz NOTE 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV 2 dBu AT ports Dante audio transport Transmission type Dante/AES-67, software selectable Connectors 2 RJ-45 to Dante interface Inputs Up to 32 stereo channels Outputs Up to 32 stereo channels Audio format 24 bit uncompressed at 48 kHz sampling rate Latency Deterministic, based on user selections: 0.25 ms, 0.5 ms, 1.0 ms (default), 2.0 ms, 5.0 ms EXP port Transmission type Proprietary Connector 1 RJ-45 Inputs 8 stereo channels Rx Outputs 8 stereo channels Tx Audio format Uncompressed, 24-bit, 48 kHz EXP cable Shielded CAT6 up to 10 meters Communications USB configuration port Number/type 1 front panel mini USB B, female Standard Ethernet over USB Serial control port 1 RS-232, 3.5 mm captive screw connector, 3-pole, female, rear panel Baud rate and protocol 300 to 115200 baud (default: 9600), 8 data bits, 1 stop bit, no parity Serial control pin configuration Captive screw: 1 = Tx, 2 = Rx, 3 = GND Ethernet control Ethernet port 1 RJ-45 connector, female Ethernet data rate 10/100/1000Base-T, half/full duplex with autodetect Protocols ARP, ICMP (Ping), DHCP, DNS, HTTPS, SFTP, SSH, TCP/IP, UDP/IP Default settings Link speed and duplex level = autodetected IP address = 192.168.254.254 Subnet mask = 255.255.255.0 Gateway = 0.0.0.0 DHCP = off Web server Up to 200 simultaneous sessions 7.0 MB non-volatile memory Program control Extron Product Configuration Software Extron Simple Instruction Set (SIS) USB host ports Number/signal type 1-port USB HID 1-port USB 2.0 Connectors 0 (Virtual USB) USB 2.0 Maximum built-in USB hubs 1 Minimum built-in USB hubs 1 USB HID Maximum built-in USB hubs 0 Minimum built-in USB hubs 0 General Power supply Internal(IEC 60320 C20 inlet) North America: Input: 120 VAC, 50-60 Hz,20A Input: 240 VAC, 50-60 Hz,15A Other regions: Input: 100-120 VAC, 50-60 Hz, minimum15A Input: 200-240 VAC, 50-60 Hz, minimum7A A redundant power supply is standard. Redundant power supply is standard Power consumption Enclosure without boards: 178 watts Enclosure fully loaded with 40 MM boards: 1001 watts Enclosure fully loaded with40 SM boards: 1165 watts Each MM board: 20.1 watts Each SM board: 23.1 watts Ambient temperature/humidity Storage: -40 to +158F (-40 to +70C) / 10% to 90%, noncondensing Operating: +32 to +122F (0 to +50C) / 10% to 90%, noncondensing Cooling Fan, right to left (as viewed from front panel) Thermal dissipation, full load MM: 3416BTU/hr SM: 3977 BTU/hr Mounting Rack mount Yes Enclosure type Metal Enclosure dimensions 21.0" H x 17.0" W x 20.0" D (12U high, full rack wide) (53.3 cm H x43.2 cm W x50.8 cm D) (Depth excludes connectors and handles.Width excludes rack ears.) Product weight (fully loaded) 126 lbs (57 kg) Regulatory compliance CE, c-UL, C-tick, FCC Class A, ICES, UL, VCCI Complies with the appropriate requirements of RoHS, WEEE. Product warranty 3 years parts and labor

FAQs of 8x8 to 320x320 Modular Fiber Optic Matrix Switcher:


Q: What is the input type for the Modular Fiber Optic Matrix Switcher?

A: The input type for the Modular Fiber Optic Matrix Switcher is AC/DC.

Q: What is the frequency specification of this switcher?

A: The frequency of this switcher is 50 Hertz (Hz).

Q: What is the primary application of the Modular Fiber Optic Matrix Switcher?

A: The switcher is primarily used in Electrical and Electronics applications.

Q: What power source does this product support?

A: It supports both AC and DC power sources.

Q: What are the key features of this Matrix Switcher?

A: The key feature of this switcher is its high quality performance.
