Two Input DTP Transmitter With Audio Embedding For Floor Boxes

Two Input DTP Transmitter With Audio Embedding For Floor Boxes

Product Details:

  • Features High Quality
  • Input AC/DC
  • Power Source AC/DC
  • Product Type electrical products
  • Application Electrical & Electronics
  • Size Standard
  • Function Electrical & Electronics Equipment
  • Click to View more
X

Two Input DTP Transmitter With Audio Embedding For Floor Boxes Product Specifications

  • AC/DC
  • Electrical & Electronics Equipment
  • High Quality
  • electrical products
  • 50 Hertz(Hz)
  • AC/DC
  • Standard
  • Electrical & Electronics
  • as shown in the image

Product Description

Key FeaturesDesigned to mount in a variety of floor boxesTransmits HDMI or analog video, control, and analog audio up to 230feet (70meters) over a shielded CATx cableAutoswitching between inputsSupports computer and video resolutions up to 1920x1200, including 1080p/60 and 2KAnalog stereo audio embeddingExtron XTPDTP24 shielded twisted pair cable is strongly recommended for optimal performance Video VGA Gain Unity Bandwidth 170 MHz (-3 dB) Crosstalk -50 dB @ 10 MHz, -30 dB @ 100 MHz Switching speed <5 ms. (max) HDMI Maximum data rate 6.75 Gbps (2.25 Gbps per color) Maximum pixel clock 165MHz Resolution range Up to 1920x1200 or 1080p @ 60 Hz; 2k Formats RGB and YCbCr digital video Standards DVI 1.0, HDMI, HDCP 1.1, CEA-861E Video input HDMI Number/signal type 1 HDMI input (or single-link DVI-D with the appropriate DVI-HDMI adapters) Connectors 1 female HDMI type A Video input VGA Number/signal type 1 VGA-QXGA; RGBHV Connectors 1 female 15-pin HD Nominal level 0.7 Vp-p for RGB Min./max. level Analog, 0.3 V to 1.5 Vp-p with no offset Impedance 75 ohms Horizontal frequency 15 kHz to 145 kHz Vertical frequency 30 Hz to 170 Hz Return loss <-40 dB @ 5 MHz NOTE The VGA input is digitized and output as DTP. The VGA signal is notscaled. Sync VGA Input type RGBHV Input level 1.9 V to 5.0 Vp-p S/N >90 dB at maximum input (unweighted) Max. input voltage 5.0 Vp-p Interconnection between transmitter and receiver Number/signal type 1 DTP 230 output Connector 1 female RJ-45 Termination standard TIA/EIA T568B Transmission distance Up to 230 (70 m) using shielded twisted pair cable or XTP DTP 24 STP cable Cable requirements Solid conductor, 24 AWG or better Cable recommendations 400 MHz bandwidth, STP (shielded twisted pair) NOTE Extron XTP DTP 24 shielded twisted pair cable is strongly recommended for optimal performance. NOTE Input and output mode signaling: DTP: HDMI with embedded audio, analog audio, RS-232 and IR, and remote power HDBaseT: HDMI with embedded audio plus RS-232 and IR Audio Gain Unbalanced output: 0 dB; balanced output +6 dB Frequency response 20 Hz to 20 kHz, 0.5 dB THD + Noise 0.01% @ 1 kHz at nominal level S/N >90 dB, at maximum input (unweighted) Crosstalk <-45 dB @ 20 kHz, or -72 dB @ 1 kHz or below Stereo channel separation >80 dB @ 1 kHz to 20 kHz Audio input Number/signal type 1 analog stereo, unbalanced or 1 digital audio, embedded in the HDMI Connectors 1 female 3.5 mm mini stereo jack 1female HDMI Type A (shared with video input) Source formats HDMI LPCM up to 7.1/24-bit/192 kHz, Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Digital 5.1, Dolby Digital 2/0 Surround, Dolby Digital 2/0, DTS-HD Master Audio, DTS-HD, DTS-ES Discrete 6.1, DTS-ES Matrix 6.1, DTS Digital Surround 5.1, DTS 2 Channel Analog Analog stereo audio Impedance 10k ohms, DC coupled Nominal level -10 dBV Maximum level +6dBV, unbalanced CMRR >60 dB typ @ 1 kHz Input gain adjustment -18 dB to +24 dB, 1 dB steps, adjustable per input NOTE 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV 2 dBu Audio output Number/signal type 1 analog audio over DTP signal, or 1 embedded digital audio over DTP signal Connectors 1 RJ-45 jack Communications switcher Serial control port RS-232 via (1) 3.5 mm, 3 pole captive screw connector Serial control pin configuration Pin 1 = Tx, pin 2 = Rx, pin 3 = Gnd Baud rate and protocol (RS-232) 9600 baud, 8 data bits, 1 stop bit, no parity USB control port 1 female mini USB, type B USB standards USB 2.0, high speed Program control Extron Simple Instruction Set (SISTM) Communications RS-232/IR over TP NOTE Protocol is mirrored between the connected DTP 230 Rx and the Over TP output port. Signals from a control device pass intothe Over TP port, are embedded with the DTP signal, and sent to the DTP 230 Rx endpoint for control of remote sink and source devices. The Over TP port is a pass-through connection to the DTP endpoint. There is no RS-232 or IR insertion from the DTP T FB 232 control port to the Over TP port. Serial control pass-through port 1 RS-232 and IR via (1) 3.5 mm, 5-pole captive screw connector Serial control pin configuration Pin 1 = Tx, pin 2 = Rx, pin 3 = Gnd Baud rates 300 to 115200 baud Protocol 8 or 7 data bits 1 or 2 stop bits no parity (default) even or odd parity IR pass-through control port TTL level (0 to 5 V) modulated infrared control from 30 kHz up to 60 kHz IR control pin configuration 3 = GND, 4 = IR Tx, 5 = IR Rx General Power supply External Input: 100 to 240 VAC, 50-60 Hz Output: 12 VDC,1.5 A,18 watts Power consumption Device 4.5 watts Device and power supply 5.5 watts Remote power budget 12 watts Ambient temperature/humidity Storage: -40 to +158 F (-40 to +70 C) / 10% to 90%, noncondensing Operating: +32 to +104 F (0 to +40 C) / 10% to 90%, noncondensing Cooling Convection, no vents Thermal dissipation Device 15.3 BTU/hr Device and power supply 18.5 BTU/hr Mounting Floor box mount Ackermann GB3/OBO Betterman floor box, MK Electric CableLink Plus Single Pan floor box, MK Electric CableLink Plus Modular floor box, ElectraPlan floor box, and PUK floor box mountable NOTE See theDTP T FB 232 User Guidefor mounting considerations. Enclosure type Metal Enclosure dimensions 2.3" H x 2.8" W x 5.2" D* (5.9 cm H x 7.2 cm W x 13.2 cm D) (Dimensions exclude connectors) * Depth is 6.1" (15.5 cm) including mounting tabs Product weight 1.1 lbs (0.5 kg) Regulatory compliance CE, c-UL UL, CE, C-tick, FCC Class A, ICES, VCCI, Complies with the appropriate requirements of RoHS, WEEE

FAQs of Two Input DTP Transmitter With Audio Embedding For Floor Boxes:


Q: What is the function of the Two Input DTP Transmitter With Audio Embedding For Floor Boxes?

A: The function of the product is Electrical & Electronics Equipment.

Q: What type of power input does the transmitter support?

A: The transmitter supports both AC and DC power input.

Q: What is the operating frequency of the transmitter?

A: The transmitter operates at a frequency of 50 Hertz(Hz).

Q: What quality can be expected from the Two Input DTP Transmitter With Audio Embedding For Floor Boxes?

A: The product is designed to deliver high quality performance.

Q: What is the size specification of the transmitter?

A: The transmitter is available in standard size.
