Fiber Optic Transmitter For HDMI USB HID Audio Control And 3D Sync

Product Description

Key FeaturesTransmits HDMI video, USB HID, stereo audio, RS-232 control, IR control, and 3D sync signals over fiber optic cablingSupports mathematically lossless 4K video up to 4096x2160 at 60 Hz with 4: 4: 4 chroma sampling over one fiberSupports uncompressed 4K video up to 4096x2160 at 60 Hz with 4: 4: 4 chroma sampling over two fibersSupported HDMI 2.0 specification features include data rates up to 18 Gbps, Deep Color up to 12-bit, and 3DHDCP 2.3 compliantDevice class filtering on USB HID port restricts the range of device types to HID specification Frame rate1 24, 25, 30, 50, or 60 fps Chroma sampling1 4: 4: 4, 4: 2: 2, or 4: 2: 0 Color bit depth1 8 bits per color Signal Type , 2.0, 1.4 Max. video data rate 10.2 Gbps (3.4 Gbps per color) NOTE 1Subject to the maximum data rate limit. Use our calculator (www.extron.com/8Kdatarate) to determine video parameters supported by this data rate. NOTE *AppropriateHDMI to DVI-D cables or adapters are required for DVI signal input/output. Video Maximum data rate 10.2 Gbps (3.4 Gbps per color) Maximum pixel clock 300 MHz Resolution range Up to 1920x1200 or 1080p @ 60 Hz;12-bit color depth, 2K 4K (4096x2160) @ 30 Hz, UHD (3840x2160) @ 30 Hz Formats RGB and YCbCr digital video Standards DVI 1.0, HDMI 1.4, HDCP 2.2, 1.4, CEA-861E Video input Number/signal type 1 single link HDMI (or DVI-D*) input Connector 1 female HDMI type A Interconnection between transmitter and receiver Signal Type 1 digital video, embedded digital audio (HDMI), and remote power Connector 1 female RJ-45 Termination standards TIA/EIA T568B Signal transmission distance 1080p @ 60 Hz Up to 230 (70 m) using shielded twisted pair (STP) cable or XTP DTP 24 cable 4K/UHD @ 30 Hz Up to 130 (40 m) using shielded twisted pair (STP) cable or XTP DTP 24 cable Cable requirements Solid conductor, 24 AWG or better NOTE Extron XTP DTP 24 shielded twisted pair cable is strongly recommended for optimal performance. NOTE Output mode signaling: DTP: HDMI with embedded audio and remote power HDBaseT: HDMI with embedded audio General Power supply External Input: 100 to 240 VAC, 50-60 Hz Output: 12 VDC,1.5 A,18 watts Power consumption Device 3.2 watts Device and power supply 3.9 watts Remote power budget 12 watts NOTE Thetransmittercan be powered either locally by the included external power supply or remotely by a powered receiver on the other end of the twisted pair cable. Ambient temperature/humidity Storage: -40 to +158 F (-40 to +70 C) / 10% to 90%, noncondensing Operating: +32 to +104 F (0 to +40 C) / 10% to 90%, noncondensing Cooling Convection, no vents Thermal dissipation Device 10.8 BTU/hr Device and power supply 13.1 BTU/hr Mounting Mountsto 1-gang enclosures with 60 mm mounting centers. Enclosure type Metal Enclosure dimensions Frame 3.17" H x 3.17" W x 0.40" D (1-gang) (80.5 mm H x80.5 mm W x10.1 mm D) Device module 2.17" H x 2.17" W x 1.52" D (55.0 mm H x55.0 mm W x38.4 mm D) Fits mounting frames that accept 55 mm x 55 mm modules. (Allow at least 1.9" [47 mm] in the junction box for device plus cable clearance.) Product weight 0.2 lbs (0.1 kg) Vibration ISTA 1A in carton (International Safe Transit Association) Regulatory compliance Safety CE, c-UL, UL EMI/EMC CE, C-tick, FCC Class A, ICES, VCCI Environmental Complies with the appropriate requirements of RoHS, WEEE.
